General Data
Wheelbase 7 foot 3 inches Track 3 foot 10 inches Turning circle 34 foot Brakes - Bendix Duo Servo, cable operated on all 4 wheels Shock absorbers - Lucas Luvax rotary hydraulic Cruciform braced chassis, underslung at the rear Sliding roof Opening windscreen with Triplex glass ( all round*) Wind down front and rear side windows Furniture hide upholstery* Interior roof light* Luggage rack* |
Engine
Capacity 1052cc Cylinders 4 Bore 60.3mm Stroke 92mm Side valve Coil ignition Solex Self Starting carburetter "Buoyant Power" flexible engine mounting |
|
Clutch
Single Borg and Beck pattern dry plate |
Lubrication
Engine 5 pints, pressure lubrication, bypass filtration Gearbox 2 pints Rear Axle 2 pints |
|
Gear ratios
First 3.94:1 Second 2.43:1 Third 1.45:1 Top 1:1 |
Final drive
38:7 spiral bevel crown wheel and pinion |
|
Maximum speeds in the gears
(corresponding to 4000 RPM) First 14 MPH Second 22 MPH Third 37 MPH Top 54 MPH |
Electrical system
12 volts Dynamo with "3rd brush" regulation Manual charging rate switch Compensated Electric fuel gauge Single screen wiper (requires manual starting and parking!) High* and low note Lucas Altette horns Flush fitting lluminated trafficators* |
